pandat_result_utility::Pandat_Result_Table Class Reference

Pandat result table controller. For PanGUI only. More...

#include <pfm_writers.h>

Static Public Member Functions
static void	initialize_pandat_result_table (map< int, shared_ptr< P_Result > > &m_result, int ppf_calc_id, vector< pair< string, string > > dbs)
static void	update_pandat_result_table (map< int, shared_ptr< P_Result > > &m_result, int ppf_calc_id, string pandat_rlt_path, double time_in_sec, double T_in_K, PFM_Stat &stat, bool is_finalized=true)
static void	update_pandat_result_table_custom (map< int, shared_ptr< P_Result > > &m_result, int ppf_calc_id, string pandat_rlt_path, double time_in_sec, double T_in_K, PFM_Stat &stat, map< string, double > &custom_property, bool is_finalized=true)
static void	update_stat_spinodal (pandat_result_utility::PFM_Stat &stat, double avg_dt, int tot_steps, map< string, double >energy_terms, VectorMesh< double > *comp_field, vector< string > comp_names, vector< string > phase_names)
static void	update_stat (PFM_Stat &stat, double avg_dt, int tot_steps, map< string, double >energy_terms, VectorMesh< double > *comp_field, vector< string > comp_names, vector< string > phase_names, VectorMesh< double > *etar)

Detailed Description

Pandat result table controller. For PanGUI only.

Member Function Documentation

initialize_pandat_result_table()

static void pandat_result_utility::Pandat_Result_Table::initialize_pandat_result_table ( map< int, shared_ptr< P_Result > > &  m_result, int  ppf_calc_id, vector< pair< string, string > >  dbs  )

inlinestatic

Initialize a pandat result table with given calculation id

Parameters

[out]	m_result	the hashmap of Pandat result tables with key of calculation id
[in]	ppf_calc_id	the key to be added
[in]	dbs	the database information to be added to result table

Returns

void

update_pandat_result_table()

static void pandat_result_utility::Pandat_Result_Table::update_pandat_result_table ( map< int, shared_ptr< P_Result > > &  m_result, int  ppf_calc_id, string  pandat_rlt_path, double  time_in_sec, double  T_in_K, PFM_Stat &  stat, bool  is_finalized = true  )

inlinestatic

Update a pandat result table with given calculation id

Parameters

[out]	m_result	the hashmap of Pandat result tables with key of calculation id
[in]	ppf_calc_id	the key to be added
[in]	pandat_rlt_path	the path of saving pandat result table
[in]	time_in_sec	the current moment of heat treatment in seconds
[in]	T_in_K	the current temperature in K
[in]	stat	the statistics of phase field model at the current moment
[in]	is_finalized	control to write xml or not

Returns

void

update_pandat_result_table_custom()

static void pandat_result_utility::Pandat_Result_Table::update_pandat_result_table_custom ( map< int, shared_ptr< P_Result > > &  m_result, int  ppf_calc_id, string  pandat_rlt_path, double  time_in_sec, double  T_in_K, PFM_Stat &  stat, map< string, double > &  custom_property, bool  is_finalized = true  )

inlinestatic

Update a pandat result table for a given calculation id along with a custom_property

Parameters

[out]	m_result	the hashmap of Pandat result tables with key of calculation id
[in]	ppf_calc_id	the key to be added.
[in]	pandat_rlt_path	the path of saving pandat result table.
[in]	time_in_sec	the current moment of heat treatment in seconds.
[in]	T_in_K	the current temperature in K.
[in]	stat	the statistics of phase field model at the current moment.
[in]	custom_property	(key,value) map of the custom properties.
[in]	is_finalized	control to write xml or not.

Returns

void

update_stat_spinodal()

static void pandat_result_utility::Pandat_Result_Table::update_stat_spinodal ( pandat_result_utility::PFM_Stat &  stat, double  avg_dt, int  tot_steps, map< string, double >  energy_terms, VectorMesh< double > *  comp_field, vector< string >  comp_names, vector< string >  phase_names  )

inlinestatic

Update statistics of spinodal decomposition

Parameters

[out]	stat	the statistics of phase field model
[in]	avg_dt	the average time step
[in]	tot_steps	the tot steps of time integral
[in]	energy_terms	the hashmap of energy terms with key of energy name
[in]	comp_field	the composition mesh
[in]	comp_names	the name of dimensions in the composition mesh
[in]	phase_names	the phase name of dimensions of the order parameter mesh

Returns

void

update_stat()

static void pandat_result_utility::Pandat_Result_Table::update_stat ( PFM_Stat &  stat, double  avg_dt, int  tot_steps, map< string, double >  energy_terms, VectorMesh< double > *  comp_field, vector< string >  comp_names, vector< string >  phase_names, VectorMesh< double > *  etar  )

inlinestatic

Update statistics of phase field model

Parameters

[out]	stat	the statistics of phase field model
[in]	avg_dt	the average time step
[in]	tot_steps	the tot steps of time integral
[in]	energy_terms	the hashmap of energy terms with key of energy name
[in]	comp_field	the composition mesh
[in]	comp_names	the name of dimensions in the composition mesh
[in]	phase_names	the phase name of dimensions of the order parameter mesh
[in]	etar	the order parameter mesh

Returns

void

---

The documentation for this class was generated from the following file:

• pfm_writers.h
